Model # | Membrane size | # of membranes | OAL (in) | Port size | Price |
PV-FRP-2540-1000 | 25x40 | 1 | 43.00" | 1/4" | Contact |
PV-FRP-2540-1000 | 40x40 | 1 | 46.00" | 1/2" | Contact |
*U denotes Universal size. Universal sizes fit all 4040 membranes from all manufacturers. When placing an order, please specify membrane manufacturer and model number in order to supply the proper adapter. |
![]()
|
|||||
|
|||||
---|---|---|---|---|---|
Model # | Membrane size | # of membranes | OAL (in) | Weight (Lb) | Price |
PV-4040-FRP | 40x40 | 1 | 44.3" | 10.2lb | Contact |
PV-4080-FRP-300 | 40x40 | 1 | 84.3" | 14.6lb | Contact |
*U denotes Universal size. Universal sizes fit all 4040 membranes from all manufacturers. When placing an order, please specify membrane manufacturer and model number in order to supply the proper adapter. |
![]()
|
||||||
|
||||||
---|---|---|---|---|---|---|
Model # | # of membranes | OAL (in) | # of supports | Span between supports | Net weight | Price |
PV-8040SE-FRP-300 | 1 | 58 in.(1472mm) | 2 | 28 in.(711x1mm) | 28kg | Contact |
PV-8080SE-FRP-300 | 2 | 99 in.(2488mm) | 2 | 56 in.(1422x1mm) | 37kg | Contact |
PV-80120SE-FRP-300 | 3 | 138 in.(3504mm) | 2 | 80 in.(2032x1mm) | 46kg | Contact |
PV-80160SE-FRP-300 | 4 | 178 in.(4520mm) | 3 | 64.02 in.(1626x2mm) | 55kg | Contact |
PV-80200SE-FRP-300 | 5 | 218 in.(5536mm) | 3 | 78 in.(1981x2mm) | 64kg | Contact |
PV-80240SE-FRP-300 | 6 | 258 in.(6552mm) | 3 | 92.01 in(2337x2mm) | 74kg | Contact |
*U denotes Universal size. Universal sizes fit all 4040 membranes from all manufacturers. When placing an order, please specify membrane manufacturer and model number in order to supply the proper adapter. |
![]()
|
|||||||
|
|||||||
---|---|---|---|---|---|---|---|
Model # | Membrane size | # of membranes | OAL (in) | Feed | Brine | Permeate | Price |
4021.OS | 4.0"x21" | 1 | 16.5 | 3/4 | 3/4 | 1/2 | Contact |
4040.OS | 4.0"x40" | 1 | 23.5 | 3/4 | 3/4 | 1/2 | Contact |
4080.OS | 4.0"x40" | 1 | 42.5 | 3/4 | 3/4 | 1/2 | Contact |
